產品中心

深溝球軸承
深溝球軸承

英制等截面薄壁深溝球軸承


  • 英制等截面薄壁深溝球軸承,C型深溝球軸承是內外圈帶有超深溝(滾道溝槽深度=球直徑的25%)的單列深溝球軸承。

bearing@hyzcgroup.com

18837917076

  • 產品詳情


英制等截面薄壁深溝球軸承

C型深溝球軸承是內外圈帶有超深溝(滾道溝槽深度=球直徑的25%)的單列深溝球軸承。


HCAA系列
軸承型號主要尺寸基本額定載荷(KN)
d  DH徑向靜載荷徑向動載荷
HCAA1025.434.9254.7631.290.84
HCAA1538.147.6254.7631.781.00
HCAA1744.4553.9754.7632.051.08




HCHAUU系列
軸承型號主要尺寸基本額定載荷(KN)
dDH徑向靜載荷徑向動載荷
HCHA10UU25.434.9256.351.290.84
HCHA15UU38.147.6256.351.781.00
HCHA17UU44.4553.9756.352.051.08




HCA\HCAUU系列
軸承型號 主要尺寸基本額定載荷(KN)
d  DH徑向靜載荷徑向動載荷
HCA20
  HCA20UU
50.863.56.353.021.75
HCA25
  HCA25UU
63.576.26.353.691.97
HCA30
  HCA30UU
76.288.96.354.402.17
HCA35
 HCA35UU
88.9101.66.355.072.36
HCA40
HCA40UU
101.6114.36.355.742.54
HCA42
HCA42UU
107.95120.656.356.092.63
HCA45
HCA45UU
114.31276.356.412.71
HCA47
HCA47UU
120.65133.356.356.762.80
HCA50
HCA50UU
127139.76.357.072.88
HCA55
HCA55UU
139.7152.46.357.783.05
HCA60
HCA60UU
152.4165.16.358.453.20
HCA65
HCA65UU
165.1177.86.359.123.35
HCA70177.8190.56.359.793.50
HCA75190.5203.26.3510.453.65
HCA80203.2215.96.3511.123.79
HCA90228.6241.36.3512.504.06
HCA100254266.76.3513.834.31
HCA110279.4292.16.3515.174.56
HCA120304.8317.56.3516.554.80




HCB\HCBUU系列
軸承型號主要尺寸基本額定載荷(KN)
d  DH徑向靜載荷徑向動載荷
HCB20
HCB20UU
50.866.6757.9384.142.57
HCB25
HCB25UU
63.579.3757.9385.072.86
HCB30
HCB30UU
76.292.0757.9385.963.14
HCB35
HCB35UU
88.9104.7757.9386.853.41
HCB40
HCB40UU
101.6117.4757.9387.783.67
HCB42
HCB42UU
107.95123.8257.9388.143.76
HCB45
HCB45UU
114.3130.1757.9388.673.91
HCB47
HCB47UU
120.65136.5257.9389.034.01
HCB50
HCB50UU
127142.8757.9389.564.15
HCB55
HCB55UU
139.7155.5757.93810.504.38
HCB60
HCB60UU
152.4168.2757.93811.394.60
HCB65
HCB65UU
165.1180.9757.93812.284.81
HCB70177.8193.6757.93813.215.02
HCB75190.5206.3757.93814.105.23
HCB80203.2219.0757.93814.995.42
HCB90228.6244.4757.93816.815.80
HCB100254269.8757.93818.646.17
HCB110279.4295.2757.93820.426.51
HCB120304.8320.6757.93822.246.85
HCB140355.6371.4757.93825.847.47
HCB160406.4422.2757.93829.458.06
HCB180457.2473.0757.93833.098.61
HCB200508523.8757.93836.709.13




HCC系列
軸承型號 d主要尺寸基本額定載荷(KN)
d  DH徑向靜載荷徑向動載荷
HCC40101.6120.659.5259.344.77
HCC42107.951279.5259.884.93
HCC45114.3133.359.52510.415.08
HCC47120.65139.79.52510.945.23
HCC50127146.059.52511.525.38
HCC55139.7158.759.52512.595.67
HCC60152.4171.459.52513.665.95
HCC65165.1184.159.52514.726.21
HCC70177.8196.859.52515.796.48
HCC75190.5209.559.52516.866.73
HCC80203.2222.259.52517.936.98
HCC90228.6247.659.52520.067.46
HCC100254273.059.52522.207.92
HCC110279.4298.459.52524.338.36
HCC120304.8323.859.52526.478.78
HCC140355.6374.659.52530.749.58
HCC160406.4425.459.52535.0510.32
HCC180457.2476.259.52539.3211.02
HCC200508527.059.52543.5911.68
HCC250635654.059.52554.2713.18
HCC300762781.059.52564.9914.50




HCUUU系列
軸承型號主要尺寸基本額定載荷(KN)
dD  H徑向靜載荷徑向動載荷
HCU40UU101.6120.6512.79.344.77
HCU42UU107.9512712.79.884.93
HCU45UU114.3133.3512.710.415.08
HCU47UU120.65139.712.710.945.23
HCU50UU127146.0512.711.525.38
HCU55UU139.7158.7512.712.595.67
HCU60UU152.4171.4512.713.665.95
HCU65UU165.1184.1512.714.756.21
HCU70UU177.8196.8512.715.796.48
HCU75UU190.5209.5512.716.866.73
HCU80UU203.2222.2512.717.936.98
HCU90UU228.6247.6512.720.067.46
HCU100UU254273.0512.722.207.92
HCU110UU279.4298.4512.724.338.36
HCU120UU304.8323.8512.726.478.78




HCD系列
軸承型號主要尺寸基本額定載荷(KN)
d  DH徑向靜載荷徑向動載荷
HCD40101.612712.713.707.81
HCD42107.95133.3512.714.197.95
HCD45114.3139.712.715.218.28
HCD47120.65146.0512.715.708.42
HCD50127152.412.716.738.74
HCD55139.7165.112.718.249.18
HCD60152.4177.812.719.799.61
HCD65165.1190.512.721.3110.03
HCD70177.8203.212.722.8210.43
HCD75190.5215.912.724.3310.83
HCD80203.2228.612.725.8411.21
HCD90228.625412.728.9111.96
HCD100254279.412.731.9412.66
HCD110279.4304.812.735.0113.34
HCD120304.8330.212.738.0314.00
HCD140355.638112.744.1315.24
HCD160406.4431.812.750.2216.41
HCD180457.2482.612.756.2717.49
HCD200508533.412.762.3618.52
HCD210533.4558.812.765.4219.01
HCD250635660.412.777.5820.86
HCD300762787.412.792.7922.92




HCF系列
軸承型號主要尺寸基本額定載荷(KN)
d  DH徑向靜載荷徑向動載荷
HCF40101.6139.719.0523.8415.83
HCF42107.95146.0519.0525.0916.26
HCF45114.3152.419.0526.3816.68
HCF47120.65158.7519.0527.6217.09
HCF50127165.119.0528.8717.51
HCF55139.7177.819.0531.3618.31
HCF60152.4190.519.0533.9019.09
HCF65165.1203.219.0536.3919.84
HCF70177.8215.919.0538.9220.59
HCF75190.5228.619.0541.4121.31
HCF80203.2241.319.0543.9522.01
HCF90228.6266.719.0548.9323.38
HCF100254292.119.0553.9624.69
HCF110279.4317.519.0558.9825.95
HCF120304.8342.919.0564.0127.16
HCF140355.6393.719.0574.0629.45
HCF160406.4444.519.0584.0731.60
HCF180457.2495.319.0594.1233.62
HCF200508546.119.05104.1835.52
HCF250635673.119.05129.2739.87
HCF300762800.119.05154.3543.72
HCF350889927.119.05179.4947.16
HCF40010161054.119.05204.5750.27



HCG\HCGUU系列
軸承型號主要尺寸基本額定載荷(KN)
d  DH徑向靜載荷徑向動載荷
HCG40101.6152.425.436.5227.20
HCG42107.95158.7525.436.5226.96
HCG45114.3165.125.438.9727.92
HCG47120.65171.4525.441.3728.86
HCG50127177.825.443.8129.76
HCG55139.7190.525.446.2630.47
HCG60152.4203.225.451.1132.21
HCG65165.1215.925.453.5632.89
HCG70
    HCG070UU
177.8228.625.458.4134.54
HCG75
HCG075UU
190.5241.325.460.8535.19
HCG80
HCG080UU
203.225425.465.7036.76
HCG90
HCG090UU
228.6279.425.473.0438.89
HCG100
HCG100UU
254304.825.480.3340.94
HCG110
HCG110UU
279.4330.225.487.6342.92
HCG120
HCG120UU
304.8355.625.494.9344.81
HCG140
HCG140UU
355.6406.425.4109.5248.42
HCG160
HCG160UU
406.4457.225.4124.1551.81
HCG180
HCG180UU
457.250825.4138.7455.01
HCG200
HCG200UU
508558.825.4153.3358.02
HCG220
HCG220UU
558.8609.625.4167.9560.87
HCG250
HCG250UU
635685.825.4189.8564.90
HCG300
HCG300UU
762812.825.4226.3771.01
HCG350
HCG350UU
889939.825.4262.8976.49
HCG400
HCG400UU
10161066.825.4299.4181.43
